Yuanda Yuanda SCZ5080XXYBEV Electric cargo van (#288)

Yuanda electric cargo van SCZ5080XXYBEV (batch #288) based on CA1080P40L2BEVA84 chassis is made in China by FAW (Sichuan) Special Purpose Vehicle Co., Ltd. The company is located in Chengdu, in Sichuan Province, China.

Yuanda SCZ5080XXYBEV electric cargo van

SCZ5080XXYBEV

Yuanda SCZ5080XXYBEV electric cargo van Yuanda SCZ5080XXYBEV electric cargo van Yuanda SCZ5080XXYBEV electric cargo van Yuanda SCZ5080XXYBEV electric cargo van
Yuanda logo Overview
ModelSCZ5080XXYBEV
Brand NameYuanda logoYuanda
Bulletin#288
Type of vehicleElectric cargo van
VIN
  • LFNA8LDC×××××××××
  • LFNA8LDE×××××××××
Country of originChina
ChassisCA1080P40L2BEVA84
Manufacturer Profile
Manufacturer
 A subsidiary of FAW Group Corporation (China First Automobile Group Corporation, First Automobile Works).
Brand
Type of manufacturerSpecial purpose vehicle manufacturer
CityChengdu
Province (Region)Sichuan Province
CountryChina
Number of vehicles*296 models
(680 items total)
* A number of models manufactured by FAW (Sichuan) Special Purpose Vehicle Co., Ltd. found in Auto-che.com vehicle database
Yuanda logo Technical specifications
#Engine modelEngine displacementEngine powerEngine manufacturer
1SJM50D-2103 cc50 kW68 hpShanghai Zhongke Shenjiang Electric Vehicle Co., Ltd.
Performance
Fuelonly electric power (EV)
Maximum speed80 km/h50 mph
ABShave
Capacity
Rated load capacity2745 kg,
2255 kg
2.7 t,
2.3 t
6,052 lbs,
4,971 lbs
Weights and Ground pressure
Curb weight5340 kg,
5830 kg
5.3 t,
5.8 t
11,773 lbs,
12,853 lbs
Gross vehicle weight rating8280 kg8.3 t18,254 lbs
Axle load distribution3000 kg / 5280 kg
3 t / 5.3 t
7,000 lbs / 11,640 lbs
Dimensions
Overall length6660 mm / 6880 mm21′11″ / 22′7″
Overall width2250 mm7′5″
Overall height2990 mm9′10″
Cargo body
Cargo body length3790 mm12′6″
Cargo body width1890 mm6′3″
Cargo body height2100 mm6′11″
Undercarriage and Suspension
Number of axles2
Wheelbase3560 mm,
3900 mm
11′9″,
12′10″
Front track1635 mm5′5″
Rear track1540 mm5′1″
Front/rear overhang1155 mm / 1945 mm,
1155 mm / 2165 mm
3′10″ / 6′5″,
3′10″ / 7′2″
Approach / departure angle18 / 15, 18 / 13 deg.
Leaf springs7 / 10+3
Tyres and Wheels
Number of tyres6
Tyres dimension7.50-16 14PR, 7.50R16 14PR
Miscellaneous
Seating capacity3
Steering controlsteering wheel
Additional Information

Top compartment closed, not open side guards material rectangular tube Q235, bolts connected to the chassis; the protective equipment material: channel Q235; section size: 100mm × 48mm; height from the ground: 470mm; Connection: the chassis bolt connecting vehicle length optional hydraulic tailgate: 6880mm, curb weight: 5830kg, load weight: 2255kg.1 battery type / model / manufacturer: lithium iron phosphate lithium-ion / CA60FI / CNAC lithium (Luoyang) Limited; battery. cell voltage / capacity: 3.2V / 60Ah, the total voltage / total capacity: 384V / 240Ah; 2 drive motor type / model / manufacturer: Three-phase permanent magnet synchronous motor / SJM50D-2103 / Shanghai in
