Dongfeng Dongfeng EQ6621LBEVT Electric bus (#283)

Dongfeng electric bus EQ6621LBEVT (batch #283) is made in China by Dongfeng Special Automobile Co., Ltd. The company is located in Shiyan, in Hubei Province, China.

Dongfeng EQ6621LBEVT electric bus

EQ6621LBEVT

Dongfeng EQ6621LBEVT electric bus Dongfeng EQ6621LBEVT electric bus Dongfeng EQ6621LBEVT electric bus
Dongfeng logo Overview
ModelEQ6621LBEVT
Brand NameDongfeng logoDongfeng
Bulletin#283
Type of vehicleElectric bus
VIN
  • LDTZ8X2G×××××××××
Country of originChina
Manufacturer Profile
Manufacturer
 A subsidiary of DFM (Dongfeng Motor Corporation).
Brand
Type of manufacturerSpecial vehicle manufacturer
CityShiyan
Province (Region)Hubei Province
CountryChina
Number of vehicles*696 models
(1900 items total)
* A number of models manufactured by Dongfeng Special Automobile Co., Ltd. found in Auto-che.com vehicle database
Dongfeng logo Technical specifications
#Engine modelEngine displacementEngine powerEngine manufacturer
1M100C-F cc60 kW82 hpZhejiang Zhongda Transmission Co., Ltd.
Performance
Fuelonly electric power (EV)
Maximum speed100 km/h63 mph
ABShave
Capacity
Passenger capacity (including driver)10-17
Weights and Ground pressure
Curb weight3750 kg3.8 t8,267 lbs
Gross vehicle weight rating5350 kg5.4 t11,795 lbs
Axle load distribution2200 kg / 3150 kg
2.2 t / 3.2 t
4,900 lbs / 6,945 lbs
Dimensions
Overall length6150 mm20′3″
Overall width2005 mm6′7″
Overall height2650 mm8′9″
Undercarriage and Suspension
Number of axles2
Wheelbase3665 mm12′1″
Front track1710 mm5′8″
Rear track1716 mm5′8″
Front overhang1005 mm3′4″
Rear overhang1480 mm4′11″
Angle of approach21°
Angle of departure17°
Leaf springs- / 3
Tyres and Wheels
Number of tyres4
Tyres dimension215/75R16C
Miscellaneous
Steering controlsteering wheel
Additional Information

Optional on the right door, optional car charger, installation speed limiting device, speed 100km / h, the car equipped with satellite positioning tachograph .ABS Model: CM4XL-4S / 4K (4S / 4M) / Guangzhou Bureau of automotive electronic control technology Co., Ltd. Battery Type / Manufacturer: composite lithium ion batteries / Jin Hua Keyuan Electronics Co., Ltd.; rated motor power / peak power: 60kw / 100kw stages of technology products for the initial period, sales to the Ministry of Finance, Ministry of Science, Industry and Information Technology. Ministry of development and reform Commission jointly issued "on the support of Beijing and Tianjin, a city or region to carry out new energy vehicles to promote the application of the notice" (Finance Building [2013] No. 805), "on the support of Shenyang, Changchun and other cities or regions open
